| System Components |
6 Pcs Motor, 1 Pc Control Box, 1 Pc Handset, 1 Pc Attendant Control Panel (ACP) |
| Side Rails |
Extra Long Four Pcs Under Side Occidental Style with Inclination Degree Indicator |
| Head and Foot Panel |
Heavy ABS with Locking and Buffers |
| Top Section |
Four Section |
| Framework |
Made Up of M.S. Tubes |
| Castors |
150 mm Central Locking ABS Castors, Durable and Quiet |
| I.V. Rod |
S.S. Telescopic with Four Locations |
| Urine Bag Holder |
Included |
| Sitting Position |
Adjustable |
| Leg Section |
Extendable |
| Finish |
Pre-Treated & Epoxy Powder Coated |
| Overall Size |
Approx 1970-2120 mm L x 900 mm W x 460-740 mm H |
| Mattress |
C4 Section Mattress (DHF - 2001C) |
| LED Lamp |
As Reading Lamp or Under Bed Lamp |
| Positions Obtained by Hand Remote: |
- Hi-Low
- Backrest Elevation
- Knee Rest Elevation
- Trendelenburg / Reverse Trendelenburg
- Fowler Position
|
| Functions on Attendant Control Panel (ACP): |
- Hi-Low with Locking Function for Handset
- Backrest Elevation with Locking Function for Handset
- Knee Rest Elevation with Locking Function for Handset
- Trendelenburg / Reverse Trendelenburg with Locking Function for Handset
- One Button Electric CPR Position and Manual CPR Function for Emergency
|
